800 900 1800 2100 2600MHz GSM LTE 2G 3G 4G Mobile Network Cell Phone Signal Booster
- Model NumberKW12D-LGDWL
- Brand NameLintratek
- Type4G Signal Booster
- FunctionALC(AGC)/MGC for outdoor use repeater/booster
- Gain60dB
- Output Power12dBm
- Frequency800/900/1800/2100/2600mhz
- Coverage100-400sqm
- ConnectorN Female
- Product Size390*200*85mm
- Net Weight1.5kg
- CertificateCE, ROHS, ISO
- Quality Warranty12 Months
Specification should care about :
| Model No | KW12D-LGDWL | |
| Parameter data | Uplink | Downlink |
| Frequency Range |
LCD:791-821MHz
GSM:890-915MHz
DCS:1710-1785MHz
WCDMA:1920-1980MHz
LTE26:2500-2570MHz
|
LCD:832-862MHz
GSM:935-960MHz
DCS:1805-1880MHz
WCDMA:2110-2710MHz
LTE26:2620-2690MHz
|
| Output Power | 10±2dBm | 12 ±2dBm |
| Gain | 55±2dB | 60±2dB |
| Bandwidth | Wide Band | |
| Automatic Gain Control | ≥ 20 dB | |
| Ripple in Band | ≤5dB | |
| Intermodulation Products | 9KHz~1GHz: ≤ -36 dBm | |
| 1GHz~12.75GHz: ≤ -30 dBm | ||
| Spurious Emission | 9KHz~1GHz: ≤ -36 dBm | |
| 1GHz~12.75GHz: ≤ -30 dBm | ||
| Noise Figure @ max. gain | ≤ 7 dB | |
| VSWR | ≤2 | |
| MTBF | >43800 hours | |
| Power Supply | AC:100~240V, 50/60Hz; DC:12V 3A | |
| Power Consumption | 10W | |
| Impedance | 50 ohm | |
| Mechanical Specification | ||
| RF Connector | N-Female | |
| Cooling | Heatsink Convection cooling | |
| Dimensions (D x W xH ) | 390*200*85mm | |
| Weight | 1.2Kg | |
| Installation Type | Wall Installation | |
| Environment Conditions | IP40 | |
| Humidity | < 90% | |
| Operating Temperature |
-25°C ~ 55°C |
|
PRODUCT DESCRIPTION
HOW TO INSTALL IT?
Trade Info:
MOQ:5pcs, sample order is welcome
Trade terms: EXW, FOB, CIF
Payment terms: T/T, L/C, western union, paypal, escrow etc.
Payment condition: 30% deposit to confirm production, balance clear before delivery.
Delivery time: 2-5 working days for sample order, 10-30 working days for bulk order
Packing: Neutral carton
Shipping: by sea, by air and by express delivery
Trading process:
After- Sales Service
We have 24 months quality guarantee for all customers, you can return goods to us when
receive defective repeater, but air freight charges should be responsible by buyer.
SAMPLE ROOM
Q1:Do you have CE or any other certification?
A:Yes,we CE,ISO,ROHS and FCC certification,etc.
Q2:Can you give me a discount?
A:We will offer discount when we hold activities.
Q3:How about gain and output power of your device?
A:Different models, gain and output power are different,for more details, please contact us.
Q4:How long is warranty period?
A:The warranty is 12 months. And we offer 7*24 technical support
Q5:What's your device lifespan?
A:Normally our device can be used 10-15 years.
Q6:how many square meters can be covered?
A:For different models, the covered square meters are different.
Q7:Can I use your device in suburbs or remote areas?
Yes, as long as you can find a good signal source, our signal booster can help you solve signal problems in remote areas.
Q8:How about gain and output power of your device?
Different models, gain and output power are different,for more details, please contact us.
